                                       DJF(b)-2 Series Hanging Exhaust Fan

                    Hanging Ventilation Exhaust Fan/Ceiling Fan for Cow House/Poultry Farm



Product Application:

DJF(b)-2Series Hanging exhaust fan is widely used in the cow house for ventilation and cooling.


Technical Parameter:

Model


Drive


Blades Diameter
(mm)
Blades Rotational Speed Motor Rotational Speed Air Flow
(m³/h)
Noise Decibels
 (db)
Input Power
(W)
Voltage
    (V)


Frequency
 (HZ)


Outline Size
(H*W*T) (mm)


DJF(b)-1-900Belt700630rpm1400rpm22000  ≤65370
220 / 380/ Customized

  50 / 60
900*900*270
DJF(b)-1-1000Belt900610rpm1400rpm25000  ≤707501000*1000*270
DJF(b)-1-1100Belt1000600rpm1400rpm32500  ≤707501100*1100*270
DJF(b)-1-1220Belt1100460rpm1400rpm38000  ≤707501220*1220*270
DJF(b)-1-1380Belt1270439rpm1400rpm44000  ≤7011001380*1380*270
DJF(b)-1-1530Belt1400325rpm1400rpm55800  ≤7015001530*1530*270

Product Description:
Hanging Ventilation Exhaust Fan/Ceiling Fan for Cow House/Poultry Farm

Fan blades


1. Material : Krupp 430 stainless steel, thickness 1.2mm
2. Diameter: 1270mm

Advantage:
Large air flow, no deformation, no fracture, no dust, attractive and durable.

Note:
Blade material also have galvanized sheet, aluminum alloy for option









Belt Pulley


1. Material: High strength aluminum-magnesium alloy by die-casting.
2. Blast-sanding treatment, eliminate internal stress to improve its own rigidity and stability

Advantage:
Light weight, Low vibration ,attractive appearance.








Hanging Ventilation Exhaust Fan/Ceiling Fan for Cow House/Poultry Farm
Hanging Ventilation Exhaust Fan/Ceiling Fan for Cow House/Poultry Farm

Safe Net


Material: Hot-dip galvanized wire is coated with Plastic

Advantage:
Double Protection to ensure never rust.






Hanging Rings
Four hanging rings are added

Advantage:
Convenient to install and adjust the angle to reach excellent performance.













Hanging Ventilation Exhaust Fan/Ceiling Fan for Cow House/Poultry Farm

Hanging Ventilation Exhaust Fan/Ceiling Fan for Cow House/Poultry Farm

Belt


Brand: Mitsuboshi belt (Japanese)
Type: A type

Advantage:
Famous brand, Long service life, maintenance free



Round Frame

Material: Hot-dip galvanized sheet with zinc thickness of 275g/sqm

Advantage:
Extremely improves the anti-corrosion performance.








Hanging Ventilation Exhaust Fan/Ceiling Fan for Cow House/Poultry Farm


Hanging Ventilation Exhaust Fan/Ceiling Fan for Cow House/Poultry Farm

Motor


1. Brand: Chinese famous motor, Siemens motor, ABB motor and WEG motor
2. Motor Protection Grade: IP55
3. Isulation Class: F grade

Advantage:
Motor voltage and frequency can be customized.
Chinese famous motor OEM by special design for fan, the first put in the phase lack protection device which would power off when shortage of electricity.








                                                 About our Company

Hanging Ventilation Exhaust Fan/Ceiling Fan for Cow House/Poultry Farm
Shandong Yuyun Sanhe Machinery Co.,Ltd is the biggest and the most professional manufacturer of ventilation equipment in
China,equipped with the most advanced CNC production lines and laser cutting machines, top quality level in the industry.
