Solar Air Conditioner Description                                                                                                     Inverter Hybrid Solar Ceiling Cassette Type Energy-Saving Air Conditioner 24000BTU


Inverter Hybrid Solar Ceiling Cassette Type Energy-Saving Air Conditioner 24000BTU


What Is Solar Air Conditioner


Recreate Hybrid Solar air conditioner is engineered from the ground up for use with solar.All electrical components are DC powered including compressor,high-efficiency DC fan motors,DC valves&solenoids,etc.
The Recreate's system uses a VRF(Variable Refrigerant Flow)controller and frequency driver in conjunction with multiple sensors and an algorithmic control circuit to raise and lower the unit's capacity in real-time based on conditions as they change.Recreate Hybrid Solar air conditioner are more powerful and use less energy than a fixed speed air conditioner.
Recreate is the inventor of world's first true Hybrid Solar air conditioner.Using Recreate's Solar direct drive technology(SDDA) the Recreate Solar Hybrid unit can use Solar DC generated power or mains AC generated power,or a combination of both as required.This means that the Recreate Hybrid requires NO batteries,NO inverter,NO controller and need only a few PV panels to deliver a huge saving.Under optimum conditions,this can save up to 97% of your mains power usage.
The SDDA will use as much solar energy as is available and this solar energy directly replaces the equivalent amount of AC power from the mains provider.Under enough solar power conditions,the Recreate Hybrid can normal operation without AC generated power.



  Inverter Hybrid Solar Ceiling Cassette Type Energy-Saving Air Conditioner 24000BTU



Inverter Hybrid Solar Ceiling Cassette Type Energy-Saving Air Conditioner 24000BTU       Inverter Hybrid Solar Ceiling Cassette Type Energy-Saving Air Conditioner 24000BTU

Benefits of Recreate ACDC Hybrid
1.  Connects Directly to the Solar Panel  Runs on up to 100% solar power directly in daytime that would save you up to 97% of your power bill.
2.  Easy Solar Connections  Connection from the solar panels to the Recreate Solar Hybrid outdoor is very simple with a terminal block mounted in the outdoor unit for the positive and negative cables straight from the solar panels.
3.  Super applicability  Wide operating temperature range-10ºC to +52ºC,Meet T3 work environment Wide operating AC voltage rangeAC 160V-250V,meet the remote network voltage instability area.
4.  Super energy-saving and Super Cooling performance  Super Cooling performance is ensured by big compressor together with the greatest heat exchange system.SEER up to 36 with solar,22 without solar.

Common Application
home / office / school / remote telecom station / desert location / island location / bus station...


A/C Unit Description                                                                                                                           Inverter Hybrid Solar Ceiling Cassette Type Energy-Saving Air Conditioner 24000BTU
Model No.RC-ADC12GW-XARC-ADC18GW-XARC-ADC24GW-XA
Power SupplySolar PowerVDC90-380V  MAX.15A
AC Power ConnectedV200-230V(50/60Hz)
CoolingCapacityBtu/h120001800024000
Inverter Capacity RangeBtu/h3099-129873482-193894294-25280
Power InputkW0.981.511.87
Rated Current(AC)A4.466.28
SEER 222020
EER 12.612.112.1
HeatingCapacity 12,00017,20023,800
Inverter Capacity RangeBtu/h3753~133064435~197895100~23542
Power InputkW1.121.291.82
Rated CurrentA5.936.088.08
HSPF 111011
COP 12.111.612.7
 Dehumidificationpt/h1.3L/h1.9L/h2.3L/h
Indoor Air Flow - (Hifan)cfm66010801210
Indoor Noise dB(A) (Hifan)dB(A)404547
Max Refrigeration Pipe Lengthft/m151515
Max Refrigeration Pipe Rise/Fallft/m555
Max Elevation Difference 151515
Design Pressurepsig550 / 340550 / 340550 / 340
ConnectionTypeflare flare flare
Connection WiringAWG4*18AWG4*18AWG4*18AWG
Operation temperatureIndoor (Cooling/Heating)ºF60.8 - 89.6/ 60.8 - 89.6 60.8 - 89.6/ 60.8 - 89.6 60.8 - 89.6/ 60.8 - 89.6
Outdoor (Cooling/Herating)ºF50- 125.6/5-104  50- 125.6/5-104  50- 125.6/5-104
Indoor UnitDimension(W*D*H) mm895×300×2031000×310×240 1130×320×245
Packing(W*D*H) mm1080×385×3271080×385×3271195*310*390
Net/Gross Weightkg9/11.112.5/14.515.5/17.5
Outdoor UnitDimension(W*D*H) mm795×290×555795×290×555860×304×733
Packing(W*D*H) mm910×400×630910×400×6301005×450×820
Net/Gross Weightkg31/3535/3951/55
Approvals CB/GCC/ Performance Certified
Container Load 20'/40'/40'HQ 84/177/20678/171/17954/115/128
